METIS-HS High Speed Elevator

Intuitive elevator distribution guidance reduces passenger waiting time and elevator running time.The linkage of the gate machine, card swipe and the DCS improves the safety and simplify the operation.


high speed lifts
high speed lifts
fast elevators
high speed elevator
average elevator speed per floor

Features Of METIS-HS High Speed Elevator


  • Multiple Security Technology.

  • Comfortable Ride Experience.

  • Power Regeneration Device.

  • DCS and Card Entrance Guard Gate Machine Linkage.


Specification Of METIS-HS High Speed Elevator


NO.Specification800(10P)1050(14P)1150(15P)
1Capacity (kg)80010501150
2Speed (m/s)33.5433.5433.54
3Lifting height(m)≤200
4Machine room height (mm)2500
5Rear weightReduced stroke1Hoistway size (mm) (net width * net depth)2000*21002200*23002300*2300
Top Floor Height(mm)530053005700530053005700530053005700
Pit depth(mm)300030003200300030003200300030003200
Car Specifications (mm) (net width * net depth * full height)1400*1350*25001600*1500*25001700*1500*2500
Door opening size (mm) (net width * net height)800*2100900*21001000*2100
6Side-to-sideReduced stroke1Hoistway size (mm) (net width * net depth)/2300*24002300*2500
Top Floor Height(mm)530053005700530053005700
Pit depth(mm)340034003650340034003650
Car Specifications (mm) (net width * net depth * full height)1200*2000*25001200*2100*2500
Door opening size (mm) (net width * net height)900*2100900*2100
2Hoistway size (mm) (net width * net depth)///
Top Floor Height(mm)
Pit depth(mm)
Car Specifications (mm) (net width * net depth * full height)
Door opening size (mm) (net width * net height)
NO.Specification1350(18P)1600(21P)2000(26P)
1Capacity (kg)1350

16002000
2Speed (m/s)33.5433.5433.54
9Lifting height(m)≤200
10Machine room height (mm)≥2600
11Rear weightReduced stroke1Hoistway size (mm) (net width * net depth)2600*2300

2600*26002500*2850
Top Floor Height(mm)530053005700530053005700530053005700
Pit depth(mm)300030003200300030003200300030003200
Car Specifications (mm) (net width * net depth * full height)1950*1500*2500

1950*1750*25001950*2050*2500
Door opening size (mm) (net width * net height)1100*2100

1100*21001100*2100
12Side-to-sideReduced stroke1Hoistway size (mm) (net width * net depth)2450*2400

2400*28002700*2800
Top Floor Height(mm)530053005700530053005700540054005600
Pit depth(mm)340034003650340034003650340034003650
Car Specifications (mm) (net width * net depth * full height)1500*2000*2500

1400*2400*25001700*2400*2500
Door opening size (mm) (net width * net height)900*2100

900*21001100*2100
2Hoistway size (mm) (net width * net depth)2300*2800

2650*2400
Top Floor Height(mm)530053005700530053005700
Pit depth(mm)340034003650340034003650
Car Specifications (mm) (net width * net depth * full height)1200*2400*2500

1700*2000*2500
Door opening size (mm) (net width * net height)900*2100

1000*2100
NO.Specification1350(18P)1600(21P)2000(26P)
1Capacity (kg)135016002000
2Speed (m/s)565656
3Lifting height(m)≤300
4Machine room height (mm)≥2600
5Hoistway size (mm) (net width * net depth)2600*24502600*26002500*2850
Top Floor Height(mm)690069006900690069006900
Pit depth(mm)440048004400480044004800
Car Specifications (mm) (net width * net depth * full height)1950*1500*28001950*1750*28001950*2050*2800
Door opening size (mm) (net width * net height)1100*2100
Note: The standard equipment adopts de-stroke technology, when the de-stroke technology is not used, the height of the top layer and the depth of the pit need to be increased.
