GRACES Commercial Escalator

IFE Elevator focuses on the Research and Developmenttherefore,our R & D department has over 200 professional engineer. Until now,we have gotten over 200national patent.


escalator cost
escalator cost
escalator lift price

Features Of GRACES Commercial Escalator


  • No need to install a machine room on the top of the building and consider buffer pits on the ground floor, taking up less space than elevators

  • Continuous and rapid evacuation of a large number of people


Specification Of GRACES Commercial Escalator


SpecificationGRACES-ID
Lifting height range/m1.5≤H≤13.0
Use segment length/m--
Tilt angle/°30/35
Nominal width/mm600/800/1000
Nominal speed/m/s0.5
Applicable environmentIndoors
The type of workNormal type
Handrail structureVertical armrests
Drag methodY-△/VVVF
Startup modeStandard single speed
Standard self-starting
Frequency conversion low speed
Frequency conversion self-starting
Number of horizontal steps as standardH≤6m2
H>6m3
Pedal depth/mm as standard--
Additional brakesH≤6mNo
H>6mYes
Truss deflection≤1/750
Safety factor for moving parts≥5


SpecificationGRACES-Ⅲ
Lifting height range/m1.5≤H≤13.0
Use segment length/m--
Tilt angle/°30/35
Nominal width/mm600/800/1000
Nominal speed/m/s0.5
Applicable environmentOutside
The type of workNormal type
Handrail structureVertical armrests
Drag methodY-△/VVVF
Startup modeStandard single speed
Standard self-starting
Frequency conversion low speed
Frequency conversion self-starting
Number of horizontal steps as standardH≤6m2
H>6m3
Pedal depth/mm as standard--
Additional brakesH≤6mNo
H>6mYes
Truss deflection≤1/750
Safety factor for moving parts≥5


SpecificationGRACES-LD
Lifting height range/m1.5≤H≤18
Use segment length/m--
Tilt angle/°27.3/30
Nominal width/mm600/800/1000
Nominal speed/m/s0.5/0.65
Applicable environmentIndoor/Outdoor
The type of workPublic transport type
Handrail structureVertical armrests
Stainless steel diagonal armrest
Drag methodVVVF
Startup modeFrequency conversion low speed
Frequency conversion self-starting
Number of horizontal steps as standardH≤6m3
H>6m3
Pedal depth/mm as standard--
Additional brakesH≤6mYes
H>6mYes
Truss deflection≤1/1000
Safety factor for moving parts≥5
