Without receiving any operation instructions, the elevator will enter standby energy-saving mode within the predetermined time after closing the door, and turn off the lighting and fan in the car.
Accurate / Comfortable.
lntelligent Technology New Experience.
| NO. | Specification | 450 | 550 | 630 | 800 | 1050 | |||||||
| 1 | Capacity (kg) | 450 | 550 | 630 | 800 | 1050 | |||||||
| 2 | Speed (m/s) | 1 | 1 | 1 | 1.75 | 1 | 1.75 | 1 | 1.75 | ||||
| 3 | Operation System | full collective selection operation | |||||||||||
| 4 | Driving System | VVVF | |||||||||||
| 5 | Door Operator System | VVVF | |||||||||||
| 6 | Traction Machine | Permanent Magnet Synchronous Gearless type | |||||||||||
| 7 | Control System | CTRL80 | |||||||||||
| 8 | Parallel Elevators | 2 units | |||||||||||
| 9 | Group Control Elevators | 3-8 units | |||||||||||
| 10 | Wide Car1 | Car Dimension mm width*depth | 1100x1100 | 1100x1300 | 1100x1400 | 1350x1400 | 1500x1600 | ||||||
| Single door shaft size(mm) | 1900x1500 | 1900x1650 | 1900x1750 | 2150x1750 | 2300x2050 | ||||||||
| W*H | |||||||||||||
| Split door shaft size(mm) | - | 1900x1810 | 1900x1910 | 2150x1910 | 2300x2110 | ||||||||
| W*H | |||||||||||||
| 12 | Wide Car2 | Car Dimension mm width*depth | - | 1300x1100 | 1400x1100 | 1100x1750 | 1100x2100 | ||||||
| Shaft Size mm W*H | - | 2100x1500 | 2200x1500 | 1900x2100 | 1900x2450 | ||||||||
